12 AWG PV Wire 2000V UL4703 — Made in USA | In Stock | Ships Same Day
Photovoltaic Cable LLC offers UL4703-certified 12 AWG Copper PV Wire rated at 2,000 Volts — the smallest gauge in our copper PV wire lineup, engineered for module-to-module connections, short panel string runs, and residential rooftop solar installations where compact, flexible wiring is required. Available in Black and Red in 500 ft reels. Compatible with standard MC4 solar connectors. All inventory ships same day from our three U.S. fulfillment centers.
When to choose 12 AWG
12 AWG is the standard specification for module-to-module jumper connections and short panel string runs where the distance is under 50 ft and the current is below 20A. Its smaller diameter makes it easier to route between panels and through tight conduit paths. For longer runs or higher currents, consider our 10 AWG PV Wire 2000V. Use our Voltage Loss Calculator to confirm the right gauge for your project.
Technical specifications
| Conductor | 19-strand copper per ASTM B-3, B-8 |
| Voltage rating | 2,000 Volts (2kV) |
| Certifications | UL 4703 — RHW-2 (UL 44) — USE-2 (UL 854) |
| Insulation | Cross-Linked Polyethylene (XLPE) |
| Temperature rating | −40°C to +90°C (wet and dry) |
| Colors | Black — Red |
| Reel size | 500 feet |
| UV resistance | Yes — sunlight and ozone resistant |
| Compliance | RoHS — Gasoline and Oil Resistant II |
| NEC compliance | Article 690 — grounded and ungrounded PV systems |
| MC4 compatible | Yes — fits standard MC4 solar connectors |
| Direct burial | Yes — rated for direct burial, conduit, and free-air |
| Origin | Manufactured in North America |
Available configurations
- 12 AWG 2000V Black — 500 ft reel
- 12 AWG 2000V Red — 500 ft reel
Recommended applications
- Module-to-module jumper connections
- Short panel string runs under 50 ft
- Residential rooftop solar installations
- DIY and small off-grid solar systems
- Both grounded and ungrounded PV systems per NEC Article 690
- Direct burial, conduit, and free-air installation
Not sure if 12 AWG is right for your system?
Use our free Voltage Loss Calculator to confirm the correct gauge for your run distance and current. If your run exceeds 50 ft or your current exceeds 20A, consider upgrading to 10 AWG PV Wire 2000V.
Shipping & availability
Both configurations are in stock and ship same day from three U.S. fulfillment centers: LaPorte, Texas — Miami Lakes, Florida — Rancho Dominguez, California. Pick-up available at all locations. Most orders arrive within 1–3 business days. Free shipping on orders over $10,000 — applied automatically at checkout.
Frequently asked questions
Is 12 AWG compatible with MC4 connectors?
Yes. Our 12 AWG copper PV wire is compatible with standard MC4 solar panel connectors, available separately in 50-pair bags.
Is 12 AWG available in longer reels?
Currently available in 500 ft reels in Black and Red. Contact our sales team at +1 305 842-6291 to discuss availability for larger project quantities.
Is this wire rated for direct burial?
Yes. UL4703-listed PV wire is rated for direct burial, conduit, and free-air installation per NEC Article 690 guidelines.
When should I use 10 AWG instead of 12 AWG?
If your string run exceeds 50 ft or your current exceeds 20A, 10 AWG will minimize voltage drop more effectively. Use our Voltage Loss Calculator to compare both options side by side.
